Automobile axle housing cleaning

Automobile axle housing cleaning machines are mainly used for cleaning the rear axles of light trucks, small cars, and heavy-duty vehicles. They are cleaned by means of electric heating and high pressure, and are called axle housing cleaning machines.

The step-through type axle housing cleaning machine is suitable for the cleaning of large batches and high cleaning requirements.

Introduction to the process flow of the equipment: door opening→manual feeding→conveying (door closing)→vacant position→surface scanning cleaning and reciprocating cleaning of the inner cavity probe→spray rinsing 1→vacant position→spray rinsing 2→vacant position→compressed air blowing water→hot air drying Dry → manual cutting (manual supplementary blowing).

Introduction to the working process of the equipment: the cleaning fluid is heated by electricity to the working temperature of -80℃, the workpiece to be cleaned is hoisted to the support block, the conveyor chain transports the workpiece to the cleaning room, rinsing, blowing water, and drying rooms, pneumatic isolation door shut down. The cleaning and rinsing pump work, the exterior cleaning system cleans the outer surface of the workpiece reciprocally, and the cleaning probe is driven by the cylinder to clean the inner cavity of the workpiece axle housing tube; the cleaning time is up, the door is opened, the workpiece enters the next room, and the above actions are repeated until After the workpiece arrives at the unloading station, it is manually blown and unloaded manually.

The reciprocating axle housing cleaning machine is suitable for small batches and high cleaning requirements for axle housing cleaning.

Introduction to the process flow of the equipment: door opening-manual feeding-conveying (door closing)-surface scanning cleaning, while the inner cavity probe reciprocating cleaning-spray rinsing-compressed air blowing-back to the feeding end.

Introduction to the equipment action process: the cleaning fluid is heated by electricity to the working temperature of -80 degrees, hoisting the surface cleaning workpiece to the support block, and the trolley transports the workpiece to the cleaning room to complete the cleaning, rinsing, pressure blowing, and the surface cleaning system to the outside of the workpiece The surface is cleaned back and forth, and the cleaning probe is driven by the cylinder to clean the inner cavity of the workpiece axle housing until the material is discharged, and the cycle starts again and again.
